Dust collector WAMFLO FOOD to food production
CHARACTERISTICS
Dust collector WAMFLO FOOD FN200 to food production
- The WAMFLO Food FN200 Dust Collector range is the result of WAM’s decades of experience in dust filtration technology.
- WAMFLO Food FN200 Dust Collectors are equipped with a cylindrically shaped stainless steel casing
- With welded flanged bottom ring which contains vertically mounted filter bag elements of various types of fabrics which are all food-grade and certified.
- An air jet filter element cleaning system is integrated in the hinged top cover.
- WAMFLO Food FN200 Dust Collectors are available with or without suction fan.
- As an option for applications with top-mounted suction fan or in case of limited headroom:
- WAMFLO Food FN200 can be equipped with a newly designed inspection door;
- Door fitted on the casing with an innovative captive twist lock system which facilitates safe access to the filter elements for inspection or maintenance.
- WAMFLO Food FN200 is supplied with an integrated modular electronic panel able to manage cleaning cycles according to the specific requirements of the work process.
- The FN200X model is suitable for operation in explosive environments.
Function
- WAMFLO Food FN200 and FN200X Dust Collectors are used for both venting and suction applications.
- The unique design of the integrated compressed air jet cleaning system guarantees high efficiency, thus minimising maintenance and reducing total plant cost ownership.
- The robustness of the casing and the zero dust residue design are the special functional features for food processing applications.
- All parts in contact with food have been tested for approval according to current regulations.
Features
- Food-grade components manufactured from FDA and EC 1935/2004-certified materials;
- Hygienic operation;
- 304L stainless steel cylindrically shaped casing with welded bottom flange;
- Filter surface: 1 ~ 21 m² (11 ~ 226 sq ft);
- Air volume: 60 ~ 2,500 m³/h (35 ~ 1470 cfm);
- High filtration efficiency thanks to WAM filtering elements;
- Tool-free maintenance and filtering element replacement;
- Multifunctional, intelligent electronic control panel;
- Bag-type filter elements;
- Comfortable maintenance height;
- Compressed air jet cleaning system integrated in top cover;
- High cleaning efficiency due to "Full Immersion" solenoid valves integrated into corrosion-resistant air tank for low maintenance operation;
- Electronic differential pressure meter (MDPE);
- Safe weather protection cover with lockable quick release;
- Increased durability;
- Reduced maintenance costs;
- Increased work safety;
- Exceptional price-quality ratio;
- Low operating costs (TCO);
