ElegaDust collector WAMFLO FOOD to food production

Dust collector WAMFLO FOOD to food production

On order

Dust collector WAMFLO FOOD to food production

info@elega.lt Call

CHARACTERISTICS

Dust collector WAMFLO FOOD FN200 to food production

  • The WAMFLO Food FN200  Dust Collector range is the result of WAM’s decades of experience in dust filtration technology.
  • WAMFLO Food FN200 Dust Collectors are equipped with a cylindrically shaped stainless steel casing
  • With welded flanged bottom ring which contains vertically mounted filter bag elements of various types of fabrics which are all food-grade and certified.
  • An air jet filter element cleaning system is integrated in the hinged top cover.
  • WAMFLO Food FN200 Dust Collectors are available with or without suction fan.
  • As an option for applications with top-mounted suction fan or in case of limited headroom:
    • WAMFLO Food FN200 can be equipped with a newly designed inspection door;
    • Door fitted on the casing with an innovative captive twist lock system which facilitates safe access to the filter elements for inspection or maintenance.
  • WAMFLO Food FN200 is supplied with an integrated modular electronic panel able to manage cleaning cycles according to the specific requirements of the work process.
  • The FN200X model is suitable for operation in explosive environments.

Function

  • WAMFLO Food FN200 and FN200X Dust Collectors are used for both venting and suction applications.
  • The unique design of the integrated compressed air jet cleaning system guarantees high efficiency, thus minimising maintenance and reducing total plant cost ownership.
  • The robustness of the casing and the zero dust residue design are the special functional features for food processing applications.
  • All parts in contact with food have been tested for approval according  to current regulations.

Features

  • Food-grade components manufactured from FDA and EC 1935/2004-certified materials;
  • Hygienic operation;
  • 304L stainless steel cylindrically shaped casing with welded bottom flange;
  • Filter surface: 1 ~ 21 m² (11 ~ 226 sq ft);
  • Air volume: 60 ~ 2,500 m³/h (35 ~ 1470 cfm);
  • High filtration efficiency thanks to WAM filtering elements;
  • Tool-free maintenance and filtering element replacement;
  • Multifunctional, intelligent electronic control panel;
  • Bag-type filter elements;
  • Comfortable maintenance height;
  • Compressed air jet cleaning system integrated in top cover;
  • High cleaning efficiency due to "Full Immersion" solenoid valves integrated into corrosion-resistant air tank for low maintenance operation;
  • Electronic differential pressure meter (MDPE);
  • Safe weather protection cover with lockable quick release;
  • Increased durability;
  • Reduced maintenance costs;
  • Increased work safety;
  • Exceptional price-quality ratio;
  • Low operating costs (TCO);
