PSS KWU Smoke Chambers capacity 600-3200 kg/ 8 h

Send enquiry
PSS KWU  Smoke Chambers,capacity 600-3200 kg/ 8 h
  • SS SCH smoke chambers are devices designed for the food industry and meat processing operations and their main task is to be involved in the manufacturing of heat-processed meat and other food products.
  • These devices greatly simplify the work mainly in meat production plants because they allow the heat treatment of smoked products in one complete production cycle, including reddening, drying, smoking and cooking.
  • The PSS SCH thus significantly contribute to the production of high-quality final products.
  • Smoke chamber trucks, evenly filled with meat products, which are ready to undertake the processing, are pushed into the smoke chamber PSS SCH.
  • There is a smooth transition of steam, smoke and air mixture through individual trucks in the chamber.
  • By the process, PSS SCH ensure the evenly flow and temperature distribution throughout the internal space of the chamber and subsequent achievement of increased quality of processed products.
  • The smoke generator is the part of the PSS SCH as well as the misting system, which provides a humidity adjustment in the smoke chamber.
  • The cleaning system ensures the perfect internal space cleaning.
  • The PSS SCH is possible to manufacture according to customer requirements and needs and in left or right design of door opening.
OPTIONS
  • Connection to PC
  • Smoke truck
  • Truck stick (smoke stick)
Main Characteristics
Parameter
PSS KWU 1 PSS KWU 2 PSS KWU 3 PSS KWU 4
Smoke chamber input, kW 28 54 81 108
Boiling chamber input, kW 27 53 80 107
Chamber weight, kg 1380 1900 2400 3100
Main dimensions (LxWxH), mm 1330x2080x3315 2395x2080x3315 3470x2080x2315
4540x2080x3715
Capacity kg/ 8 h 600-800 1200-1600 1800-2400 2400-3200
No. of trucks, pcs 1 2 3 4
Voltage network 3/PE/N, 50Hz, 230/400V 3/PE/N, 50Hz, 230/400V 3/PE/N, 50Hz, 230/400V 3/PE/N, 50Hz, 230/400V
Control voltage 230 V 230 V 230 V
230 V
