ElegaNextGuard TM X-ray Detection System

NextGuard TM X-ray Detection System

On order

NextGuard TM X-ray Detection System

info@elega.lt Call

CHARACTERISTICS

NextGuard TM X-ray Detection System

  • Meet a broad range of food safety and quality requirements with the Thermo Scientific™ NextGuard™ X-ray Detection System.
  • An affordable foreign object detection system for a wide variety of food applications.
  • NextGuard X-ray Detection System is now designed with enhanced capabilities to inspect packaged products for missing pieces or components, under and over-fills, and contaminants using new, easily customizable vision software.
  • It is an easy-to-use, cost effective and thoughtfully designed system that eliminates common barriers to transitioning from metal detection to x-ray detection.

Product Description:

New and improved NextGuard X-ray Detection System Features:

  •     Product verification software option allows users to execute a wide range of size, position and count inspections.
  •     Additional algorithms target the detection of less dense contaminants such as glass or rocks in complex, textured products such as nuts or tea bag boxes.
  •     Optional mass estimation software uses the density information in the X-ray image to estimate weight and detect under/over filled products.
  •     Configurable for dual rejection, separating contaminated products from other quality errors.
  •     Standard system processor is now six times faster than the first generation NextGuard system, supporting high-speed contaminant detection and inspection as well as improved user responsiveness.
  •     Optional 0.4mm-pixel detector offers 3.2 times better resolution for improved metal detection in lightweight, homogeneous products such as powders or cheese.

Additional Benefits:

  •     Compact size for easy installation and use
  •     Unique non-linear detector to eliminate inspection blind spots
  •     Removable conveyor for simple directional change and maintenance
  •     Intuitive Thermo Scientific™ VersaWeigh™ user interface and software
  •     Modular design for high reliability and quick diagnosis and repair
  •     Source and detector lifetime indicators to minimize expensive downtime
  •     Built-in remote monitoring for quick problem determination

Options to Customize Your System:

  •     Complete rejection systems or rejection mechanisms for use on downstream conveyor
  •     Stainless steel air conditioner for washdown environments
  •     Alarm horn, no lead curtains, casters, guiderails
  •     Radiation safety meters
  •     UL or CSA site inspection
  •     Spare parts kits

FULL SPECIFICATIONS:
Aperture Width and Height : 340 mm x 185 mm (13.4 x 7.3 in.).
Belt Material:
USDA/FDA approved urethane.
Belt Speed:
Variable speed: 10 - 80 m/min. (262 ft./min.) for.
Certifications/Compliance:
ISO9001 certified facility.
Converyor Heights Available: (
specify at order) 800 mm (31.5 in.), 900 mm (35.4 in.), 1,000 mm (39.4 in.), 1,100 mm (43.3 in.).
Description:
NextGuard X-ray Detection System.
Detection Algorithms Available:
Simple threshold, gradient, morphologies and contaminant area measure.
Detector Resolution:
Unique design with no inspection blind spots, 0.8mm or optional 0.4mm pixel size.
Detector Scan Rate:
Up to 1,667 lines per second.
Digital Inputs:
Four inputs, 24VDC 25 mA, NPN/PNP (jumper selectable), assignable function.
Digital Outputs:
Four outputs, 24VDC 0.5A, assignable function.
Export/Safety Conformance:
CE, IRR99, NCF 74-100, UNE 73-302.
Interface:
Windows™ 7, touchscreen, 307 mm (12.1 in) diagonal.
Interface Languages: English, Spanish, French, Italian, German, simplifed Chinese, Russian and Polish. Contact the factory for additional languages.
Network Port: Watertight Ethernet port standard.
Operating Temperature:
5° to 30°C (41° to 86°F) with cooling fan or 5° to 40°C (41° to 104°F) with air conditioner.
Outputs:
Excel, PDF, or xml format selectable.
Rejector:
Integrated variable speed conveyors. Air blast or pusher. Lockable reject bin and reject/bin full photo sensors.
Relative Humidity:
20 - 90% non-condensing.
Safety Features:
X-ray power key, four level password system, emergency X-ray/conveyor stop button, lead/lead-free curtains, failsafe LED x-ray imminent and on indication light.
USB Port:
Watertight USB 2.0 standard.
Weight (Metric):
320 kg.
X-Ray Power:
160 Watts or 100 Watts, 40 - 80kV.
Sensitivity:
≥0.5mm diameter for steel, ≥1.5mm for other dense contaminants (depends on the relative density of the contaminant as compared to the package).
IP Rating: IP65 with air conditioner, IP54 with cooling fans. Full stainless steel type 304 construction.
Radiation Safety Conformance: FDA CFR 21 part 1020.40, RED act. Others available, contact the factor.
