External motovibrator MVE-D
Documents
CHARACTERISTICS
External motovibrator MVE-D
- Explosion-Proof MVE-D External Electric Motovibrators consist of an electric motor housed in a sturdy FMEA-designed cast casing, with eccentric weights fitted on both shaft ends.
- Special design features and tight tolerances avoid that any possible explosion inside the motor will affect the external environment.
- Making the explosion-proof MVE-D suitable for applications in the oil & gas industry where such a feature is mandatory.
Function
- Explosion-proof MVE-D External Electric Motovibrators can be used:
- as flow aids on hoppers or silos to improve material discharge, or
- as drives for conveying, screening, dewatering,
- or fluid recovery on vibrating machines, especially in the oil & gas industry,
- and occasionally in the recycling sector.
- When the MVE is switched on a sinusoidal centrifugal force is provided by the rotation of the eccentric weights.
- With only one MVE fitted on a vibrating machine a rotating force is provided resulting in a circular movement of the machine.
- Two counter-rotating MVE fitted in parallel on the same machine provide a linear force resulting in a linear movement of the machine.
- The requirement of circular or linear movement depends on the application.
- Most applications in the oil & gas sector use two MVE Motovibrators per machine to generate linear movement.
Features
- Centrifugal force: 800 ~ 5,500 k.g
- Vacuum-impregnated windings using Class F insulating materials.
- Premium quality bearings.
- Sturdy FMEA-designed casing.
