AIRSOL OIL-Modular air filter units for oil-mist

Send enquiry
AIRSOL OIL-Modular air filter units for oil-mist
Areas of applications
  • Centralized installations for the fitration of oil mists
  • Centralized installations for the fitration of emulsion mist
  • Centralized installations at service of machine tools, CNC machines, lathes, milling machines and other types of machines for the metalworking with coolant
  • Filtration of oil mists and emulsion mist on drill, milling machine, boring machine, lathe, grinding machine, Planing mill, shaping machine, slotting, grinding, broaching machine
Features
  • Strong construction in galvanized and painted sheet
  • Plenum chamber with drain siphon and liquid collection
  • Filter frame with condensates drainage system
  • 3-stage fitration: droplet separator, pre-fitration with metallic mesh, fial fitration with multipleat fiter
  • F7 class fial fitration (EN 779), optionally available with higher fitration class
  • Inspection hatch
  • Sealing and blocking system of the fiters with eccentric blade
  • Airsol modularity: the fiters can be combined in parallel to achieve very high flw rates
AIRSOL/OIL TECHNICAL DATA
Model
Max.
flowrate
m3/h
ðP
max,
(mm H2O)
Dimension,
mm
Module
Weight,
kg
AS1/2/O
2000
60
320x600x820
A
100
AS1//O
3500
60
640x600x820
B
120
AS2/O
7000
60
1280x600x820
C
225
AS3/O
10500
60
1920x600x820
D
300
AS4/3/O
10500
60
1300x1300x2100
E
700
AS4/O
14000
60
1300x1300x2100
E
750
AS6/O
21000
60
1950x1300x2100
F
1150
AS7/O
24500
60
2600x1300x2100
2xE
1300
AS8/O
28000
60
2600x1300x2100
2xE
1350
AS12/O
42000
60
3900x1300x2100
3xE
1900
